Description
The Passenger Elevators from evolve joins essentials of care, solace, security, and speed carefully. Guaranteeing the greatest possible level of protected and smooth vertical experience with next to no speed misfire, the creative innovation took on by Evlove Elevators has empowered it to expand lift vehicles, offering a more agreeable and open ride without fail.
Design
Evolve Passenger Elevators are intended to upgrade comfort at your home. Aside from that, it additionally saves the space, adds more class and mixes with contemporary engineering. By delightfully amalgamating stylish feeling, innovation mix and client fulfilment, we convey the client what they wish in the most effective way. Different planning choices for vehicle and vehicle top lightings can be chosen as shown.
CAPACITY | SPEED | LOAD | LIFT WELL WXD | PLATFORM WXD | CAR INSIDE WXD | ENTRANCE Center Open | MACHINE ROOM (WIDTH) | MACHINE ROOM (DEPTH) | PIT DEPTH | OVER HEAD(Min.) | CAR INSIDE SQ.MTR. | |||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
PERSONS | MPS | K.G | W | D | W | D | W | D | W | w | D | |||
6 | 1.0/1.5 | 408 | 1650 | 1600 | 1250 | 1100 | 1190 | 950 | 700 | 4350 | 3550 | 1600 | 4800 | 1.13 |
8 | 1.0/1.5 | 544 | 1800 | 1700 | 1400 | 1200 | 1340 | 1050 | 800 | 4500 | 3350 | 1600 | 4800 | 1.4 |
2.0/2.5 | 544 | 1800 | 1700 | 1400 | 1200 | 1340 | 1050 | 800 | 4500 | 3350 | 2500 | 5350 | 1.4 | |
10 | 1.0/1.5 | 680 | 1800 | 1900 | 1400 | 1450 | 1340 | 1300 | 800 | 4500 | 3850 | 1600 | 4800 | 1.74 |
1.0/1.5 | 680 | 1800 | 1900 | 1400 | 1450 | 1340 | 1300 | 800 | 4500 | 3850 | 1600 | 4800 | 1.74 | |
13 | 2.0/2.5 | 884 | 2000 | 2200 | 1600 | 1600 | 1540 | 1450 | 900 | 4700 | 4150 | 2500 | 6000 | 2.23 |
2.0/2.5 | 884 | 2000 | 2200 | 1600 | 1600 | 1540 | 1450 | 900 | 4700 | 4150 | 2500 | 6000 | 2.23 | |
16 | 1.0/1.5 | 1088 | 2200 | 2300 | 1800 | 1700 | 1740 | 1550 | 1000 | 4900 | 4250 | 1600 | 4800 | 2.69 |
2.0/2.5 | 1088 | 2200 | 2300 | 1800 | 1700 | 1740 | 1550 | 1000 | 4900 | 4250 | 2500 | 6000 | 2.69 | |
20 | 1.0/1.5 | 1360 | 2200 | 2600 | 1800 | 1950 | 1740 | 1800 | 1000 | 4900 | 4550 | 1800 | 4800 | 3.13 |
2.0/2.5 | 1360 | 2200 | 2600 | 1800 | 1950 | 1740 | 1800 | 1000 | 4900 | 4550 | 2500 | 6000 | 3.13 | |
26 | 1.0/1.5 | 1768 | 2800 | 2600 | 2300 | 1850 | 2240 | 1700 | 1200 | 5500 | 4550 | 2500 | 6000 | 3.8 |
2.0/2.5 | 1768 | 2800 | 2600 | 2300 | 1850 | 2240 | 1700 | 1200 | 5500 | 4550 | 2500 | 6000 | 3.8 |
