Description
For transporting product vertically needs meticulously designed elevators. Elevator style needs conscientious efforts to match numerous wants. There area unit several criteria to be thought of rigorously whereas planning product elevators like, size and product to be transported, technique of handling or the ambiance during which elevate operates. Evolve Elevators has designed and provide array of product to satisfy the necessity of assorted industries. At Evolve Elevators, we tend to assist you altogether ways in which and means that serving to you achieved the correct vertical transportation.
LOAD | SPEED | LIFT WELL WXD | PLATFORM WXD | CAR INSIDE WXD | ENTRANANCE MANUAL DOOR | MACHINE ROOM (WIDTH) | MACHINE ROOM (DEPTH) | PIT | OVER HEAD (Min.) | CAR INSIDE SQ.MTR. | |||
PERSONS | MPS | W | D | W | D | W | D | W | W | D | |||
1000KG | 0.5 | 2250 | 2200 | 1450 | 1950 | 1400 | 1800 | 1000 | 4950 | 4150 | 1600 | 4800 | 2.58 |
1500KG | 0.5 | 2550 | 2400 | 1750 | 2150 | 1700 | 2000 | 1200 | 5250 | 4350 | 1600 | 4800 | 3.35 |
2000KG | 0.5 | 2550 | 2900 | 1750 | 2650 | 1700 | 2500 | 1500 | 5250 | 4850 | 1600 | 4800 | 4.31 |
2500KG | 0.5 | 2850 | 2900 | 2050 | 2650 | 2000 | 2500 | 1500 | 5550 | 4850 | 1600 | 4800 | 5 |
3000KG | 0.5 | 2850 | 3400 | 2050 | 3150 | 2000 | 3000 | 1800 | 5550 | 5350 | 1600 | 5000 | 6.16 |
4000KG | 0.5 | 3350 | 3400 | 2550 | 3150 | 2500 | 3000 | 2000 | 6050 | 5350 | 1600 | 5200 | 7.51 |
5000KG | 0.5 | 3350 | 4000 | 2550 | 3750 | 2500 | 3600 | 2000 | 6050 | 5950 | 1600 | 5200 | 9.2 |
